3748 lbs / 1,700 kg Load Rating. Built for reality.
Not a marketing ceiling. A tested number. Pressed under 10,000 tons of force, tested to JWL-T methodology on VIA-approved equipment (the Japanese benchmark used for trucks and buses).
Around 22 lbs / 10 kg. Across every offset.
Your vehicle is already working hard under load. A wheel that achieves a 3748 lbs / 1,700 kg load rating at around 22lbs / 10 kg means the drivetrain is carrying what the build demands, and nothing more. That is what forged construction makes possible. Cast wheels cannot say the same.
Physically Tested. No exceptions.
Many aftermarket brands only rely on computer simulation. We put each wheel design through physical testing to JWL-T methodology on VIA-approved equipment. Every load rating. Every time.
Every offset. Same standard.
ET0 through ET+35. Each receives the same structural engineering, the same weight discipline, the same physical validation. Your fitment is not a compromise.
FEATURES
| Material | Forged 6061-T6 Aluminum |
|---|---|
| Construction | Monoblock, pressed under 10,000 tons |
| Size | 17 x 8.5J |
| Load Rating | 1,700 kg / 3,748 lbs |
| Center Bore | 106.1mm (+0.1 / -0mm) |
| PCD | 6 x 139.7mm |
| Lug Seat | 60 degree Conical |
| Testing Methodology | JWL-T methodology on VIA-approved equipment |
| Structural Warranty | Lifetime |
| Finish Warranty | 3 Years |
| Offset | Backspacing | Weight |
|---|---|---|
| ET0 | 4.75" | 9.8 kg / 21.6 lbs |
| ET+12 | 5.22" | 9.8 kg / 21.6 lbs |
| ET+25 | 5.73" | 9.9 kg / 21.8 lbs |
| ET+35 | 6.12" | 10.2 kg / 22.5 lbs |
All weights include ±0.2 kg manufacturing tolerance. For 'Coming soon' products, confirmed weights are published prior to production.
